Feature:
1. Smart Testing: The coating thickness gauge can record the average value, maximum value, minimum value, and quantity value at the same time. The measurement range of 0?2000um and high accuracy ensure easier working. With automatic shutdown function to save battery power.
2. Clear Display: Paint depth gauge with large display will clearly show the metal type, operating mode, data, battery status and reading in um or mils.
3. Wider Utility: Used to measure the thickness of coatings and inks, widely used in manufacturing, metal processing industry, chemical industry, commodity inspection and other fields.
4. Better Design: The high definition display screen of the paint meter has a background light, making it much easier to read the data. The non slip design is comfortable to hold, which can be placed anywhere and is easy to carry.
5. Reliable Work: Able to inspect the paint thickness as well as detecting the concealed dent and blemish, very practical and reliable.
Specification:
Item Type: Paint Thickness Gauge
Model: HW 300PRO
Material: ABS
Measuring Range: 02000um
Measurement Accuracy: +(3percent +1um)
Resolution: 0um~999um (1um)
0 Calibration: Supports
Statistics: Average, Minimum, Maximum, Number
Minimum Convex Arc: Approx. 5mm 0.2in
Minimum Concave Arc: Approx. 25mm 0.98in
Minimum Measuring Area Diameter: Approx. 20mm 0.79in
Magnetic Induction: Measuring principle on F probe, eddy current effect on N probe.
Minimum Substrate Thickness: 0.2mm for F probe, 0.05mm for N probe.
Maximum Measurement Speed: 2 readings per second.
Power Supply: 2 x 1.5v AAA battery, delivered without battery.
Operating Environment:
Temperature: 0~50 celsius 2090percent relative humidity, non condensing.
Humidity: 10~60 celsius 20~90percent relative humidity, non condensing. .
Package List:
1 x
Paint Thickness Gauge6 x Calibration Film1 x Base Sheet1 x User ManualSmart Testing: The coating thickness gauge can record the average value, maximum value, minimum value, and quantity value at the same time. The measurement range of 0?2000um and high accuracy ensure easier working. With automatic shutdown function to sav
Clear Display: Paint depth gauge with large display will clearly show the metal type, operating mode, data, battery status and reading in um or mils.
Wider Utility: Used to measure the thickness of coatings and inks, widely used in manufacturing, metal processing industry, chemical industry, commodity inspection and other fields.
Better Design: The high definition display screen of the paint meter has a background light, making it much easier to read the data. The non slip design is comfortable to hold, which can be placed anywhere and is easy to carry.
Reliable Work: Able to inspect the paint thickness as well as detecting the concealed dent and blemish, very practical and reliable.
